HELIX-CI3-W200FM-S3

Woofer de alto rendimiento de 8''/200 mm con impedancia de 3 Ω, tecnología FlexMount y cono de papel recubierto Cenosphere

Descripción del producto

Technical data

Power handling RMS / max.

P

100 / 150 Watts

Impedance

Z

3 Ω

DC resistance

Re

3.0 Ω

Frequency response

50 Hz - 3,000 Hz

Resonance frequency

Fs

67 Hz

Mechanical Q factor

Qms

4.25

Electrical Q factor

Qes

0.93

Total Q factor

Qts

0.76

Compliance

Cms

300 µm/N

Equivalent air volume

Vas

19.0 L

Force factor

B*I

5.1 Tm

Sensitivity

SPL

94 dB @ 2.83 V / 1m

90 dB @ 1W / 1m

Cone area

Sd

214 cm²

Moving mass

Mms

18.8 g

Cone material

Paper with Cenosphere coating

Mechanical resistance

Rms

1.87 kg/s

Voice coil diameter

ø

25 mm

Voice coil winding height

11.6 mm

Max. linear excursion

Xmax

+/- 3.8 mm

Outer diameter

ø

195 mm / 7.68"

Outer diameter with universal mounting ring

ø

208.9 mm / 8.22"

Installation diameter

ø

173.5 mm / 6.83"

Installation depth

63.7 mm / 2.51"

Features

ProConnect terminal,

FlexMount200,

grille

Compatibility

Flexmount200

WireKits

Scope of delivery

2 x Ci3 W200FM-S3

2 x Universal mounting ring with grille

2 x Mounting material
