HELIX M SIX

Output power RMS / max.

- @ 4 Ohms 6 x 100 / 200 Watts

- @ 2 Ohms 6 x 100 / 200 Watts

- @ 1 Ohm -

- bridged @ 4 Ohms 3 x 200 / 400 Watts

- bridged @ 2 Ohms -

Amplifier technology Class D

Inputs 6 x RCA / Cinch

1 x Remote In

Input sensitivity RCA / Cinch 0.5 - 6 Volts

Input impedance RCA / Cinch 20 kOhms

Input impedance highlevel -

Outputs 6 x Speaker output

Output voltage RCA / Cinch -

Signal converter for digital input -

Frequency response 10 Hz - 30,000 Hz

Bass boost -

Highpass 15 Hz - 4,000 Hz adjustable

Lowpass 40 Hz - 4,000 Hz adjustable

Bandpass 15 Hz - 4,000 Hz adjustable

Subsonic / HPF

15 Hz - 4,000 Hz adjustable

Phase -

Slope high- / lowpass 12 dB/Oct.

Slope subsonic / lowpass -

Signal-to-noise ratio digital input -

Signal-to-noise ratio analog input 98 dB (A-weighted)

Distortion (THD) 0.05 %

Damping factor 100

Operating voltage 10.5 - 16 Volts (max. 5 sec. down to 6 Volts)

Idle current 1,550 mA

Fuse 2 x 35 A Maxi-fuse (APX)

Additional features Active, adjustable crossover, subsonic input mode switch channel E / F, subsonic, Start-Stop capability

Dimensions (H x W x D) 50 x 320 x 154 mm
