HELIX-CI5-S200FM-D2

Woofer híbrido avanzado de 200 mm / 8'' con bobina móvil dual de 2 x 2 Ω y profundidad de instalación extremadamente reducida

Descripción del producto

Technical data

Power handling RMS / Max.

P

200 / 400 Watts

Impedance

Z

2 x 2 Ω

DC resistance

Re

3.6 Ω

Frequency response

25 Hz - 500 Hz

Resonance frequency

Fs

55 Hz

Mechanical Q factor

Qms

8.31

Electrical Q factor

Qes

0.88

Total Q factor

Qts

0.80

Compliance

Cms

256 µm/N

Equivalent air volume

Vas

13.5 L

Force factor

B*I

6.7 Tm

Sensitivity

SPL

90 dB @ 2.83 V / 1m

87 dB @ 1W / 1m

Cone area

Sd

194 cm²

Moving mass

Mms

32 g

Cone material

Injected polypropylene

Mechanical resistance

Rms

1.39 kg/s

Voice coil diameter

ø

38 mm

Voice coil winding height

20 mm

Max. linear excursion

Xmax

+/- 7.5 mm

Outer diameter

ø

195 mm / 7.68"

Installation diameter

ø

173.5 mm / 6.83"

Installation depth

47.0 mm / 1.85"

Features

FlexMount200

Compatibility

FlexMount200

Scope of delivery

2 x Ci5 S200FM-D2

2 x Mounting material
